Small screws for twist lock base

Trying to identify the small screws that mount the base of the twist lock hood pins to the core support. The present ones have such a small head that they hardly hold the mounts in place, and I am curious what others have found in their unmolested cars. Is there an AMK replacement for these little screws?
murf104 is offline   Reply With Quote
Old 03/29/2009, 10:37 AM   #2
somethingspecial

somethingspecial's Avatar


Joined: Aug 05
Posts: 1,766

My Garage
They are the same screws that the inner fender splash aprons use. AMK makes the kits for the splash aprons, so there is your source. Most times the holes in the radiator support extentions the twist lock base mounts to get oversized. Before you try to mount the new screws in place, see if you can close the holes up somehow, possibly by flattening the area around the hole. The metal gets flared out oversize, by flattening the metal it will close up the hole a bit. Good Luck.
somethingspecial is offline   Reply With Quote
Old 03/29/2009, 04:13 PM   #3
mechanicalguy48

mechanicalguy48's Avatar


Location: Poulsbo Washington
Joined: Dec 08
Posts: 77

Send a message via Yahoo to mechanicalguy48
Is this the screw your reffering to Murf or another one. [IMG][/IMG]
mechanicalguy48 is offline   Reply With Quote
Old 03/29/2009, 05:13 PM   #4
murf104


Joined: Feb 03
Posts: 272

Yes, the screw ictured is the one I am concerned about. there are two others on the opposite side of the bracket which are the same size? Is the one you picture typical of all CS cars? What other places are these same screws used on our cars?
murf104 is offline   Reply With Quote
Old 03/29/2009, 05:33 PM   #5
somethingspecial

somethingspecial's Avatar


Joined: Aug 05
Posts: 1,766

My Garage
Quote:
Originally Posted by murf104 View Post
Yes, the screw ictured is the one I am concerned about. there are two others on the opposite side of the bracket which are the same size? Is the one you picture typical of all CS cars? What other places are these same screws used on our cars?
See my post above, Same as the inner fender splash aprons. Mike
somethingspecial is offline   Reply With Quote
Old 03/29/2009, 06:36 PM   #6
mechanicalguy48

mechanicalguy48's Avatar


Location: Poulsbo Washington
Joined: Dec 08
Posts: 77

Send a message via Yahoo to mechanicalguy48
The head on those is 3/8 inch. The only inner fender piece that has those is the inner fender to firewall transition piece, is that what your talking about somethingspecial ? They do appear to match the head and type of screw but there is only one per side, I guess it doesnt matter if you can order them.
mechanicalguy48 is offline   Reply With Quote
Old 03/29/2009, 07:05 PM   #7
Mosesatm

Mosesatm's Avatar


Location: Spokane, Washington
Joined: Jan 05
Posts: 7,382

Should they be natural or painted?
Mosesatm is offline   Reply With Quote
Old 03/29/2009, 07:12 PM   #8
somethingspecial

somethingspecial's Avatar


Joined: Aug 05
Posts: 1,766

My Garage
Only one is visible from the top as you indicate, the rest are located under the fender and attach the splash aprons to the firewall on the rear of the fender and to the fender forward of the front wheel. There are a total of seven screws per side. Part #55914-S2. I hope this clear things up!

Last edited by somethingspecial; 03/29/2009 at 08:13 PM..
somethingspecial is offline   Reply With Quote
Old 03/29/2009, 07:18 PM   #9
Mosesatm

Mosesatm's Avatar


Location: Spokane, Washington
Joined: Jan 05
Posts: 7,382

My AMK underhood kit shows the washer bottle, voltage regulator, and starter solenoid using screws that look like the hood pin bracket screws.
Mosesatm is offline   Reply With Quote
Old 03/29/2009, 07:20 PM   #10
murf104


Joined: Feb 03
Posts: 272

Are they also the same screw that is used to mount the starter soloniod and the voltage regulator? Do the original screws have any distinctive markings in the recess of the head such as a circle, diamond, a "D"? Were they painted, or cad plated or phosphate and oil.
The screws I have are completly incorrect and of course want to replace them with the proper screws with the correct coating.
murf104 is offline   Reply With Quote
Old 03/29/2009, 08:06 PM   #11
somethingspecial

somethingspecial's Avatar


Joined: Aug 05
Posts: 1,766

My Garage
I believe the starter solenoid and voltage regulator screws are zinc plated. The ones in question are phosphate and oil with a diamond in the recess of the head. Mike
somethingspecial is offline   Reply With Quote
Old 03/29/2009, 09:01 PM   #12
mechanicalguy48

mechanicalguy48's Avatar


Location: Poulsbo Washington
Joined: Dec 08
Posts: 77

Send a message via Yahoo to mechanicalguy48
Yeah I agree, they appear to be phosphate and oil , hoever mine do not have any markings on the head.
